Артикул: 2TYZ510205G0701 · Производитель: ABB · EAN: 6925897543895

2TYZ510205G0701

Name: BMH/U2.1.1-885
Brand: ABB
SKU: 2TYZ510205G0701
Availability: PreOrder

Под заказ

Наличие в РФ

нет в наличии

Склад в Китае

18 569.39 ₽

срок ≈1 мес. (38 дн.)

Склад в Европе

16 821.68 ₽

срок ≈1 мес. (38 дн.)

Запросить цену / заказать

Movement Detector HF KNX, Basic, black Detection Range (Circular): - Mounting height 2.5 m: Ø max. 10 m - Mounting height 3.0 m: Ø max. 12 m - Mounting height 4.0 m: Ø max. 10 m Technology: - 5.8 GHz HF (High Frequency) radar technology - Penetrates materials such as drywall, wood, and glass - 2 independent channels - Integrated KNX bus coupler Please refer to the installation instructions for proper setup and optimal performance. Integrated Sensors: - Brightness sensor - Temperature sensor - Humidity sensor Functions: - Movement detector with 2 power-off stages - Integrated monitoring/surveillance function - Constant light switching with up to 2 independent channels - Brightness-dependent switching of two light circuits - KNX Data Secure Installation Options: - Recessed ceiling: Hole size Ø 68 mm - Surface mounting: With PMA/A1.xx-88x housing - British Standard box: PMA/K1.1-88x - VDE flush-mounted box: PMA/K2.xx-88x

Варианты поставки

Склад	Цена	Срок	Наличие	Мин. партия
Склад в Европе	16 821.68 ₽	≈1 мес. (38 дн.)	под заказ	—	Заказать
Склад в Европе	18 125.83 ₽	≈1 мес. (59 дн.)	под заказ	—	Заказать
Склад в Китае	18 569.39 ₽	≈1 мес. (38 дн.)	под заказ	—	Заказать
Склад в Европе	19 343.87 ₽	≈4 мес. (122 дн.)	под заказ	—	Заказать
Склад в Китае	20 009.03 ₽	≈1 мес. (59 дн.)	под заказ	—	Заказать
Склад в Китае	21 353.62 ₽	≈4 мес. (122 дн.)	под заказ	—	Заказать
Склад в Китае	22 206.64 ₽	≈1 мес. (45 дн.)	под заказ	—	Заказать
Склад в Европе	34 198.22 ₽	≈1 мес. (45 дн.)	под заказ	—	Заказать
Склад в Китае	37 751.28 ₽	≈1 мес. (45 дн.)	под заказ	—	Заказать
Склад в Европе	50 701.62 ₽	уточняется	под заказ	—	Заказать

Характеристики

color	black matt
Mounting Type	Flush-mounted
Mounting Position	Ceiling
Mounting Height	Optimum 2.5 ... 4 m
Modular Components Included	Complete Device
Ambient Air Temperature	Operation -5 ... +45 °C
Degree of Protection	IP20
Function	Lightning, Logic functions, with strain relief, Activating/deactivating test mode, Adjusting the sensitivity, Brightness sensor, Temperature sensor, Humidity Sensor
Number of Channels	2
Compatible Bus Systems	KNX (TP)
Product Range	KNX
Transmission Standard	2-Wire, Twisted Pair Wiring
Cover Mounting Type	Snap On
Manual Operation	No
Number of Batteries	0
Sensor Detection Range	360 °, Frontal 5 m, Lateral 6 m, Radial 6 m, Tangential 6 m
Motion Detector Features	Creep-Under Protection
Security Standard	KNX Data Secure
Rated Current (In)	18 mA
Surface Finishing	Lacquered, Matt
Material	Plastic, Thermoplastic
RAL Number	Similar to RAL 9005
Color	black matt
Product Net Width	80 mm
Product Net Height	80 mm
Product Net Depth / Length	40 mm
Product Net Weight	57 g
Built-In Depth (t2)	40 mm
E-Number (Finland)	2815956
E-Number (Sweden)	1741111
E-Number (Switzerland)	535334612
RoHS Information	Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
REACH Information	True - contains substances > 0.1 mass percentage
REACH Date	20250625
WEEE Category	5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B	Business To Consumer
Cyber Security Software Support Period	5 year
EU Data Act Applicability and Compliance	Applicable - Compliant
ETIM 9	EC001582 - Movement sensor for bus system
ETIM 10	EC001582 - Movement sensor for bus system
eClass	V11.0 : 27143144
extended_product_type	BMH/U2.1.1-885
category_paths	Products > Low Voltage Products and Systems > Building and Home Automation Solutions > KNX > Presence Detection > Motion Detectors
