Артикул: 2CSR252001R1634
· Производитель: ABB
· EAN: 8012542870401
2CSR252001R1634
В наличии на нашем складе
18 189.25 ₽
минимальная цена
· срок от 28 дн.
Запросить цену / заказать
The RCBOs DS200 series has the function to protect against overload and short-circuit currents; protection against the effects of sinusoidal alternating earth fault currents; protection against indirect contacts and additional protection aganist direct contacts.
Варианты поставки
| Склад | Цена | Срок | Наличие | Мин. партия | |
|---|---|---|---|---|---|
| Склад в Европе | 18 189.25 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Европе | 18 189.25 ₽ | ≈4 нед. (28 дн.) | под заказ | — | Заказать |
| Склад в Европе | 18 189.25 ₽ | ≈4 нед. (28 дн.) | под заказ | — | Заказать |
| Склад в Европе | 19 451.65 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Европе | 19 451.65 ₽ | ≈3 мес. (112 дн.) | под заказ | — | Заказать |
| Склад в Европе | 19 451.65 ₽ | ≈3 мес. (112 дн.) | под заказ | — | Заказать |
| Склад в Европе | 19 880.61 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Европе | 19 880.61 ₽ | ≈1 мес. (49 дн.) | под заказ | — | Заказать |
| Склад в Европе | 19 880.61 ₽ | ≈1 мес. (49 дн.) | под заказ | — | Заказать |
| Наш склад | 21 734.00 ₽ | уточняется | 2 шт. | — | Заказать |
| Склад в Европе | 28 704.75 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Европе | 28 704.75 ₽ | ≈1 мес. (35 дн.) | под заказ | — | Заказать |
| Склад в Европе | 28 704.75 ₽ | ≈1 мес. (35 дн.) | под заказ | — | Заказать |
| Склад в Европе | 29 055.95 ₽ | уточняется | под заказ | — | Заказать |
Характеристики
| slug | ds202-ac-c63-0-03 |
| canonical_url | https://new.abb.com/products/2CSR252001R1634/ds202-ac-c63-0-03 |
| datasheet_url | https://new.abb.com/smartlinks/en?ProductId=2CSR252001R1634&Language=en&PrintPreview=False&pid=2CSR252001R1634 |
| documents_cid | 9AAC126541 |
| abb_library_url | https://library.e.abb.com/public/filter?q=9AAC126541&languageCode=en&Type=Document |
| abb_download_center | http://www.abb.com/abblibrary/DownloadCenter/ |
| Type of Residual Current | Type AC |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (400 V AC) 10 kA |
| Power Supply Connection | Arbitrary |
| Electrical Endurance | 10000 cycle |
| Number of Protected Poles | 2 |
| Number of Poles | 2P |
| Number of Earth Leakage Circuit Breakers (ELCBs) | 1 |
| Operating Characteristic | Instantaneous |
| Position of Neutral Terminals | ['Right', 'Left'] |
| Release Type | C |
| Accessories Available | Yes |
| Connecting Capacity | ['Busbar 10 mm²', 'Rigid 25 ... 25 mm²', 'Flexible 25 ... 25 mm²'] |
| Short-Circuit Current Rating (SCCR) | 30 mA |
| Tripping Characteristic | C |
| Rated Voltage (Ur) | 230 V AC |
| Rated Operational Voltage | 230 V AC |
| Rated Current (In) | 63 A |
| Rated Residual Current | 30 mA |
| Rated Short-Circuit Capacity | 6 kA |
| Maximum Breaking Capacity | 6 kA |
| Rated Frequency (f) | 50 … 60 Hz |
| Power Loss | Total 17.4 W |
| RoHS Declaration | [{'text': '9AKK106713A5607', 'doc_id': '9AKK106713A5607', 'url': 'https://library.e.abb.com/public/9AKK106713A5607?section=null&lang=en'}] |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| RoHS Date | 20211115 |
| REACH Declaration | [{'text': '9AKK108467A9482', 'doc_id': '9AKK108467A9482', 'url': 'https://library.e.abb.com/public/9AKK108467A9482?section=null&lang=en'}] |
| REACH Information | True - contains substances > 0.1 mass percentage |
| REACH Date | 20240429 |
| Conflict Minerals Reporting Template (CMRT) | [{'text': '9AKK108468A3363', 'doc_id': '9AKK108468A3363', 'url': 'https://library.e.abb.com/public/9AKK108468A3363?section=null&lang=en'}] |
| SCIP | 0883ca58-f477-455e-85c4-28116a3dd2e6 Italy |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Consumer |
| Ambient Air Temperature | ['Operation -25 ... +55 °C', 'Storage -40 ... +70 °C'] |
| Resistance to Vibrations | 20 Cycles with Load 0.8 In: 1g or 0.1mm 5...150...5 Hz |
| Resistance to Shock acc. to IEC 60068-2-27 | 25g 2 shocks 13 ms |
| Environmental Information | [{'text': 'Refer to RoHS', 'doc_id': 'Refer to RoHS', 'url': 'https://library.e.abb.com/public/Refer to RoHS?section=null&lang=en'}] |
| Product Net Width | 70 mm |
| Product Net Height | 93 mm |
| Product Net Depth / Length | 69 mm |
| Product Net Weight | 475 g |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Gross Weight | 0.48 kg |
| EAN | 8012542870401 |
| Declaration of Conformity - CE | [{'text': '9AKK106713A5607', 'doc_id': '9AKK106713A5607', 'url': 'https://library.e.abb.com/public/9AKK106713A5607?section=null&lang=en'}] |
| Instructions and Manuals | [{'text': '9AKK107045A1451', 'doc_id': '9AKK107045A1451', 'url': 'https://library.e.abb.com/public/9AKK107045A1451?section=null&lang=en'}] |
| Data Sheet, Technical Information | [{'text': '9AKK107991A8329', 'doc_id': '9AKK107991A8329', 'url': 'https://library.e.abb.com/public/9AKK107991A8329?section=null&lang=en'}] |
| ETIM 9 | EC002281 - Distributor assembly with combination RCCB/MCB |
| ETIM 10 | EC002281 - Distributor assembly with combination RCCB/MCB |
| UNSPSC | 39121601 |
| eClass | V11.0 : 27400618 |
| Object Classification Code | F |
| Standards | ['IEC/EN 60947-2', 'IEC/EN 61009-1'] |
| extended_product_type | DS202 AC-C63/0.03 |
| category_paths | Products > Low Voltage Products and Systems > Modular DIN Rail Products > Residual Current Devices RCDs > Residual Current Circuit Breakers with Overcurrent Protection RCBO |
| related_articles | 1SDA068059R1 |
