Артикул: 2CSF204001R3400
· Производитель: ABB
· EAN: 8012542781905
2CSF204001R3400
В наличии на нашем складе
Наличие в РФ
7 304.00 ₽
в наличии на складе · 25 шт.
Склад в Китае
6 478.62 ₽
срок ≈1 мес. (45 дн.)
Склад в Европе
7 038.57 ₽
срок ≈1 мес. (38 дн.)
The RCCBs F200 series assures protection to people and installations against fault current to earth. A large offer for standard instantaneous and selective AC and A types is completed with some configurations for special applications.
Варианты поставки
| Склад | Цена | Срок | Наличие | Мин. партия | |
|---|---|---|---|---|---|
| Склад в Китае | 6 478.62 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Европе | 7 038.57 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Наш склад | 7 304.00 ₽ | В наличии | 25 шт. | — | Заказать |
| Склад в Китае | 7 769.85 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Европе | 7 802.72 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в России | 7 812.02 ₽ | 5 дн. | 54 шт. | — | Заказать |
| Склад в Европе | 8 019.70 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Китае | 8 595.07 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Китае | 8 613.39 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Европе | 9 977.08 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Китае | 11 013.66 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Европе | 12 152.96 ₽ | уточняется | под заказ | — | Заказать |
Характеристики
| Carbon Footprint (Full Lifecycle) | 10.476348 kg CO₂ eq |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 82.05 % |
| ABB Site Meeting Group Waste To Landfill Target | No non-hazardous waste is sent to a landfill, UL 2799 Zero Waste To Landfill Validation available |
| Sustainable Material Content in Packaging (wt. %) | Recycled Paper - 0 %, Recycled Paper - 3.91 %, Recycled Cardboard - 29.08 %, Recycled Cardboard - 61.23 %, Recycled Cardboard - 2.66 % |
| Extended Product Lifetime | Product Durability |
| Offered with Takeback Services | Take Back for Recycling |
| Type of Residual Current | Type AC |
| Test Voltage (Ut) | 110-254 V |
| Maximum Surge Current | 0.25 kA |
| Leakage Current Type | AC |
| Power Supply Connection | Arbitrary |
| Electrical Endurance | 10000 cycle |
| Mechanical Endurance | 20000 cycle |
| Number of Poles | 4P |
| Number of Modular Spacings per DIN Rail | 4 |
| Operating Characteristic | Instantaneous |
| Position of Neutral Terminals | Right |
| Tightening Torque | 2.8 N·m |
| Accessory Type | Auxiliary contact, Auxiliary/Signal contact, Shunt trip, Undervoltage release, Overvoltage release, Motor Operating Device, Bottom fitting auxiliary contact, Autoreclosing Unit |
| Screw Terminal Type | Failsafe Bi-directional Cylinder-lift Terminal, Cage Terminal, Failsafe Biconnect Fork Top/Bottom, Failsafe Biconnect Fork Bottom |
| Accessories Available | Yes |
| Connecting Capacity | Busbar 10 mm², Rigid 25 ... 25 mm², Flexible 25 ... 25 mm² |
| Rated Cross-Section | 4 - Multi-Wired 0...25 mm², 1 - Solid-Core 25...25 mm² |
| Wire Stripping Length | 12 mm |
| Terminal Type | Screw Terminals |
| Rated Voltage (Ur) | 230/400 V |
| Rated Operational Voltage | 230 … 400 V AC |
| Rated Insulation Voltage (Ui) | 500 V |
| Rated Impulse Withstand Voltage (Uimp) | 4 kV |
| Input Voltage Type | AC |
| Rated Current (In) | 40 A |
| Rated Residual Current | 300 mA |
| Rated Conditional Short-Circuit Current (Inc) | 10 kA |
| Frequency (f) | 50/60 Hz |
| Rated Frequency (f) | 50/60 Hz |
| Power Loss | at Rated Operating Conditions per Pole 3.2 W, Total 9.6 W |
| RAL Number | Similar to RAL 7035 |
| Number of Modules | 4 |
| Maximum Operating Voltage UL/CSA | 480Y / 277 V AC |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| RoHS Date | 20211115 |
| REACH Information | True - contains substances > 0.1 mass percentage |
| REACH Date | 20240429 |
| SCIP | e8229506-bdcb-47ec-b10f-6ae72c1a19bf Italy |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Consumer |
| Ambient Air Temperature | Operation -25 ... 55 °C, Storage -40 ... 70 °C |
| Degree of Protection | Terminals IP20, Housing IP40 |
| Pollution Degree | 2 |
| Resistance to Vibrations | 20 Cycles with Load 0.8 In: 1g or 0.1mm 5...150...5 Hz |
| Resistance to Shock acc. to IEC 60068-2-27 | 25g 2 shocks 13 ms |
| Width in Number of Modular Spacings | 4 |
| Product Net Width | 70 mm |
| Product Net Height | 85 mm |
| Product Net Depth / Length | 69 mm |
| Product Net Weight | 360 g |
| Built-In Depth (t2) | 69 mm |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Gross Weight | 0.415 kg |
| Mounting Type | DIN-Rail |
