Артикул: 2CDS211001R0255 · Производитель: ABB · EAN: 4016779630696

2CDS211001R0255

Name: SH201-B25
Brand: ABB
SKU: 2CDS211001R0255
Availability: InStock

В наличии на нашем складе

Наличие в РФ

519.00 ₽

в наличии на складе · 5 шт.

Склад в Китае

275.17 ₽

срок ≈2 мес. (73 дн.)

Склад в Европе

362.75 ₽

срок ≈1 мес. (38 дн.)

Запросить цену / заказать

Compact Home SH200 miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 6 kA at 230/400 V AC) and rated currents (up to 40 A). All MCBs of the product range SH200 comply with IEC/EN 60898-1, allowing the use for residential applications.

Варианты поставки

Склад	Цена	Срок	Наличие	Мин. партия
Склад в Китае	275.17 ₽	≈2 мес. (73 дн.)	под заказ	—	Заказать
Склад в Европе	362.75 ₽	≈1 мес. (38 дн.)	под заказ	—	Заказать
Склад в Европе	381.51 ₽	≈4 мес. (122 дн.)	под заказ	—	Заказать
Склад в Китае	400.44 ₽	≈1 мес. (38 дн.)	под заказ	—	Заказать
Склад в Европе	417.71 ₽	≈2 мес. (73 дн.)	под заказ	—	Заказать
Склад в Китае	421.14 ₽	≈4 мес. (122 дн.)	под заказ	—	Заказать
Склад в Китае	459.70 ₽	≈1 мес. (45 дн.)	под заказ	—	Заказать
Склад в Китае	467.79 ₽	≈2 мес. (73 дн.)	под заказ	—	Заказать
Склад в Европе	487.54 ₽	≈1 мес. (59 дн.)	под заказ	—	Заказать
Наш склад	519.00 ₽	В наличии	5 шт.	—	Заказать
Склад в России	522.73 ₽	5 дн.	20 шт.	—	Заказать
Склад в Китае	538.19 ₽	≈1 мес. (59 дн.)	под заказ	—	Заказать
Склад в Европе	623.44 ₽	уточняется	под заказ	—	Заказать
Склад в Европе	707.94 ₽	≈1 мес. (45 дн.)	под заказ	—	Заказать
Склад в Китае	781.50 ₽	≈1 мес. (45 дн.)	под заказ	—	Заказать

Характеристики

Recyclability Rate of the Product acc. to EN45555	Design for Closing Resource Loops - Standard EN45555 - 92.1 %
ABB Site Meeting Group Waste To Landfill Target	No non-hazardous waste is sent to a landfill
Extended Product Lifetime	Product Durability
Dielectric Test Voltage	50 / 60 Hz - 1 min 2 kV
Power Supply Connection	Arbitrary
Contact Position Indication	ON / OFF
Energy Limiting Class	3
Electrical Endurance	20000 AC cycle
Mechanical Endurance	20000 cycle
Number of Protected Poles	1
Number of Poles	1P
Tightening Torque	2 N·m
Actuator Type	Toggle
Screw Terminal Type	Cage Terminal
Actuator Marking	I / O
Actuator Material	Insulation Group II, Black, Sealable
Recommended Screw Driver	Pozidriv 2
Accessories Available	No
Connecting Capacity	Conductor 25 / 25 mm², Flexible with Ferrule 0.75 ... 16 mm², Flexible 0.75 ... 16 mm², Rigid 0.75 ... 25 mm², Stranded 0.75 ... 25 mm²
Installation Size	acc. to DIN 43880 1
Terminal Type	Screw Terminals
Tripping Characteristic	B
Rated Operational Voltage	acc. to IEC 60898-1 230 V
Operational Voltage	Maximum (Incl. Tolerance) 253 V AC, Minimum 12 V AC
Rated Insulation Voltage (Ui)	acc. to IEC/EN 60664-1 440 V
Rated Impulse Withstand Voltage (Uimp)	4 kV, at 2000 m 5 kV, at Sea Level 6.2 kV
Input Voltage Type	AC
Rated Current (In)	25 A
Rated Short-Circuit Capacity	(AC) 6 kA, (230 / 400 V AC) 6 kA, (230 V) 6 kA
Rated Conditional Short-Circuit Current (Inc)	(230 V) 6 kA, (400 V) 6 kA
Rated Frequency (f)	50 / 60 Hz
Power Loss	3.2 W, at Rated Operating Conditions per Pole 3.2 W
Overvoltage Category	III
Housing Material	Insulation Group II, RAL 7035
RoHS Information	Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
RoHS Date	20260312
REACH Information	False - does not contain substances > 0.1 mass percentage
REACH Date	20260312
WEEE Category	5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B	Business To Business
Ambient Air Temperature	Operation -25 ... +55 °C, Storage -40 ... +70 °C
Reference Ambient Air Temperature	30 °C
Degree of Protection	IP20, Enclosure with Cover IP40
Pollution Degree	2
Environmental Conditions	28 cycles, with 55 °C / 90-96 %, and 25 °C / 95-100 %
Resistance to Vibrations	20 Cycles with Load 0.8 In: 5g 5 ... 150 ... 5 Hz
Resistance to Shock acc. to IEC 60068-2-27	25g 2 shocks 13 ms
Width in Number of Modular Spacings	1
Product Net Width	17.5 mm
Product Net Height	85 mm
Product Net Depth / Length	69 mm
Product Net Weight	0.105 kg
Pole Net Weight	0.125 kg
Built-In Depth (t2)	69 mm
Package Level 1 Units	carton 10 piece
Package Level 1 Gross Weight	1.09 kg
E-Number (Finland)	3210971
Mounting on DIN Rail	TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715, TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
Mounting Position	any
ETIM 9	EC000042 - Miniature circuit breaker (MCB)
