Артикул: 2CDG510029R0011
· Производитель: ABB
· EAN: 4053546111354
2CDG510029R0011
Под заказ
Наличие в РФ
нет в наличии
Склад в Китае
47 623.09 ₽
срок ≈1 мес. (38 дн.)
Склад в Европе
37 843.54 ₽
срок уточняется
For controlling 8 independent blind or roller shutter drives. The bus can be connected via enclosed terminal block.
Варианты поставки
| Склад | Цена | Срок | Наличие | Мин. партия | |
|---|---|---|---|---|---|
| Склад в Европе | 37 843.54 ₽ | уточняется | под заказ | — | Заказать |
| Склад в Европе | 43 140.92 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Европе | 45 500.35 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Европе | 47 275.80 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Китае | 47 623.09 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Китае | 50 227.66 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Китае | 52 187.57 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Китае | 55 173.38 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Европе | 68 928.29 ₽ | уточняется | под заказ | — | Заказать |
| Склад в Европе | 84 967.00 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Китае | 93 794.74 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
Характеристики
| color | grey |
| Mounting Type | DIN-Rail |
| Degree of Protection | IP20 |
| Special Functions | Switching |
| Number of Outputs | 8 |
| Number of LEDs | 1 |
| Compatible Bus Systems | free@home (TP) |
| Product Range | free@home |
| Manual Operation | No |
| Number of Batteries | 0 |
| Current Type | AC/DC |
| Voltage Range | 110 ... 230 V AC |
| Output Voltage (Uout) | 230 V AC |
| Rated Current (In) | 6 A |
| Maximum Switching Current | 6 A |
| Maximum Switching Power | 1200 W |
| Power Loss | 3 W, Total 3 W |
| Color | grey |
| Width in Number of Modular Spacings | 8 |
| Product Net Width | 140 mm |
| Product Net Height | 90 mm |
| Product Net Depth / Length | 63.5 mm |
| Product Net Weight | 0.502 kg |
| Built-In Depth (t2) | 63.5 mm |
| E-Number (Finland) | 2830084 |
| E-Number (Norway) | 4549595 |
| E-Number (Sweden) | 1816010 |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 30.6 % |
| ABB Site Meeting Group Waste To Landfill Target | No non-hazardous waste is sent to a landfill |
| Extended Product Lifetime | Product Durability, Product Modularity, Lifetime extension of customer’s assets is made possible thanks to offering and the supporting services |
| Offered with Takeback Services | Take Back for Recycling |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| REACH Information | True - contains substances > 0.1 mass percentage |
| REACH Date | 20260312 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Consumer |
| Cyber Security Software Support Period | 2 year |
| EU Data Act Applicability and Compliance | Applicable - Compliant |
| ETIM 9 | EC001330 - Shutting actuator for bus system |
| ETIM 10 | EC001330 - Shutting actuator for bus system |
| eClass | V11.0 : 27143128 |
| UNSPSC | 39121801 |
| extended_product_type | BA-M-8.230.1.1 |
| category_paths | Products > Low Voltage Products and Systems > Building and Home Automation Solutions > free@home > Blind / Shutter / Shading Control > Flush Mounted Inserts |
