Артикул: 2CDG510023R0011
· Производитель: ABB
· EAN: 4053546111590
2CDG510023R0011
Под заказ
Наличие в РФ
нет в наличии
Склад в Китае
6 820.82 ₽
срок ≈1 мес. (38 дн.)
Склад в Европе
5 420.01 ₽
срок уточняется
2 channels can be connected with conventional push-buttons or auxiliary contacts. The information of contact scanning can be used to control free@home actuators or for indicate status information. The contact scanning voltage are made available by binary input device. The devices are supplied by free@home bus, there is no additional power supply neccessary. The compact design allows the installation of conventionell 60 mm installation box or device box.
Варианты поставки
| Склад | Цена | Срок | Наличие | Мин. партия | |
|---|---|---|---|---|---|
| Склад в Европе | 5 420.01 ₽ | уточняется | под заказ | — | Заказать |
| Склад в Европе | 6 178.86 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Европе | 6 516.63 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Китае | 6 820.82 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Европе | 6 954.55 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Китае | 7 193.68 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Китае | 7 447.92 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Китае | 7 677.10 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Европе | 9 871.92 ₽ | уточняется | под заказ | — | Заказать |
| Склад в Европе | 11 469.80 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Китае | 12 661.47 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
Характеристики
| color | grey |
| Mounting Type | Flush Mounted |
| Degree of Protection | IP20 |
| Sub-Function | LED controlling |
| Number of Inputs | 2, Analog (0 ... 10 V / 4 ... 20 mA) 2 |
| Number of Input Channels | 2 |
| Number of Output Channels | 2 |
| Compatible Bus Systems | free@home (TP) |
| Product Range | free@home |
| Manual Operation | No |
| Suitable for C-Load | No |
| Number of Batteries | 0 |
| Input Voltage Type | Pulsed |
| Power Loss | 0.25 W, Total 0 W |
| Color | grey |
| Product Net Width | 39 mm |
| Product Net Height | 12 mm |
| Product Net Depth / Length | 40 mm |
| Product Net Weight | 0.043 kg |
| E-Number (Finland) | 2815947 |
| E-Number (Sweden) | 1816018 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| REACH Information | False - does not contain substances > 0.1 mass percentage |
| REACH Date | 20260821 |
| SCIP | c7e1c58e-8508-44fe-a9d1-095675ed0266 Germany |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Consumer |
| Cyber Security Software Support Period | 2 year |
| EU Data Act Applicability and Compliance | Applicable - Compliant |
| ETIM 9 | EC001584 - I/O device for bus system |
| ETIM 10 | EC001584 - I/O device for bus system |
| eClass | V11.0 : 27143145 |
| Object Classification Code | A |
| extended_product_type | BI-F-2.0.2 |
| category_paths | Products > Low Voltage Products and Systems > Building and Home Automation Solutions > free@home > Standard Inputs |
