Артикул: 2CDG120092R0011
· Производитель: ABB
· EAN: 4053546160185
2CDG120092R0011
Под заказ
Наличие в РФ
нет в наличии
Склад в Китае
27 086.06 ₽
срок ≈1 мес. (38 дн.)
Склад в Европе
24 536.79 ₽
срок ≈1 мес. (38 дн.)
The Electromotor Valve Drive KNX ST/K1.2 provides precise control for heating and cooling valves, ensuring secure communication through KNX Data Secure. It is equipped with an integrated temperature sensor and an integrated room temperature controller. It delivers a high actuating force of up to 220 N and a maximum valve stroke of 8 mm. It features 2 universal binary inputs, supporting connection options such as window contacts, presence detectors, and push-buttons. The second input also supports external temperature sensors. Additionally, the drive includes automatic valve adaptation and is compatible with a wide range of valve adapters, making it universally applicable. 2 adapters for the most common valves (M30x1.5 and Danfoss RA -VA 10 & VA 100-) are supplied. The Bus Coupler is integrated. The device can be used in the heating circuit distributor. The actual valve position can be indicated by 5 LEDs.
Варианты поставки
| Склад | Цена | Срок | Наличие | Мин. партия | |
|---|---|---|---|---|---|
| Склад в Европе | 24 536.79 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Европе | 26 441.48 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Китае | 27 086.06 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Европе | 28 217.49 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Китае | 29 188.65 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Китае | 31 149.18 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Китае | 34 060.03 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Европе | 38 872.51 ₽ | уточняется | под заказ | — | Заказать |
| Склад в Европе | 52 452.44 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Китае | 57 902.05 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Европе | 62 289.18 ₽ | уточняется | под заказ | — | Заказать |
Характеристики
| color | white |
| Mounting Type | Built-in |
| Modular Components Included | Complete Device |
| Degree of Protection | IP21 |
| Number of Digital Inputs | 2 |
| Number of Inputs | Analog (0 ... 10 V / 4 ... 20 mA) 1 |
| Compatible Bus Systems | KNX (TP) |
| Product Range | KNX |
| Manual Operation | No |
| Number of Batteries | 0 |
| Security Standard | KNX Data Secure |
| Voltage Range | 12 ... 30 V DC |
| Power Loss | 0.35 W, Total 0 W |
| Color | white |
| Product Net Width | 50 mm |
| Product Net Height | 64 mm |
| Product Net Depth / Length | 80.3 mm |
| Product Net Weight | 0.02 kg |
| E-Number (Finland) | 2815743 |
| E-Number (Norway) | 4544707 |
| E-Number (Sweden) | 1740998 |
| E-Number (Switzerland) | 405710205 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| REACH Information | False - does not contain substances > 0.1 mass percentage |
| REACH Date | 20260312 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Consumer |
| Cyber Security Software Support Period | 2 year |
| EU Data Act Applicability and Compliance | Applicable - Compliant |
| ETIM 9 | EC000792 - Actuating drive for bus system |
| ETIM 10 | EC000792 - Actuating drive for bus system |
| eClass | V11.0 : 27143135 |
| Object Classification Code | A |
| extended_product_type | ST/K1.2 |
| category_paths | Products > Low Voltage Products and Systems > Building and Home Automation Solutions > KNX > Heating, Ventilation and Air Conditioning > Electromotor Valve Drives |
