Артикул: 2CCG001246R0001
· Производитель: ABB
· EAN: 7612271517151
2CCG001246R0001
В наличии на нашем складе
Наличие в РФ
49 126.66 ₽
в наличии на складе · 10 шт.
Склад в Китае
22 851.89 ₽
срок ≈2 мес. (73 дн.)
Склад в Европе
31 071.23 ₽
срок ≈1 мес. (38 дн.)
S803P-D125 High Performance Circuit Breaker. D Characteristic. 50kA, 125A, 3P
Варианты поставки
| Склад | Цена | Срок | Наличие | Мин. партия | |
|---|---|---|---|---|---|
| Склад в Китае | 22 851.89 ₽ | ≈2 мес. (73 дн.) | под заказ | — | Заказать |
| Склад в Китае | 27 962.71 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Европе | 31 071.23 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Европе | 31 866.03 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Китае | 34 299.40 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Китае | 35 176.79 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Европе | 37 469.60 ₽ | ≈2 мес. (73 дн.) | под заказ | — | Заказать |
| Склад в Китае | 38 848.22 ₽ | ≈2 мес. (73 дн.) | под заказ | — | Заказать |
| Склад в Европе | 40 198.24 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Европе | 43 062.57 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Китае | 44 374.68 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Китае | 47 536.61 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в России | 49 126.66 ₽ | 5 дн. | 10 шт. | — | Заказать |
| Склад в Европе | 51 404.13 ₽ | уточняется | под заказ | — | Заказать |
| Наш склад | 73 779.00 ₽ | В наличии | 4 шт. | — | Заказать |
Характеристики
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 86.29 % |
| ABB Site Meeting Group Waste To Landfill Target | No non-hazardous waste is sent to a landfill |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (415 V AC) 50 kA, (440 V AC) 30 kA, (500 V AC) 10 kA, (690 V AC) 4.5 kA, (375 V DC) 30 kA |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (240 / 415 V AC) 40 kA |
| Contact Position Indication | ON / OFF / TRIP |
| Energy Limiting Class | 3 |
| Number of Protected Poles | 3 |
| Number of Poles | 3P |
| Tightening Torque | 3.5 N·m |
| Release Type | D |
| Actuator Marking | I / O |
| Recommended Screw Driver | Pozidriv 2 |
| Accessories Available | Yes |
| Connecting Capacity | Flexible 1...50 mm², Rigid 1...70 mm² |
| Wire Stripping Length | 19 mm |
| Tripping Characteristic | D |
| Rated Operational Voltage | acc. to IEC 60898-1 400 V AC, acc. to IEC 60947-2 690 V AC |
| Rated Insulation Voltage (Ui) | acc. to IEC/EN 60664-1 690 V |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Input Voltage Type | AC/DC |
| Rated Current (In) | 125 A |
| Rated Short-Circuit Capacity | (400 V AC) 15 kA |
| Frequency (f) | 50/60 Hz |
| Rated Frequency (f) | 50/60 Hz |
| Power Loss | Total 28.2 W, at Rated Operating Conditions per Pole 9.4 W |
| Overvoltage Category | III |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| RoHS Date | 20230505 |
| REACH Information | False - does not contain substances > 0.1 mass percentage |
| REACH Date | 20250313 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Business |
| Ambient Air Temperature | Operation -40 ... 70 °C, Storage -40 ... 70 °C |
| Reference Ambient Air Temperature | 30 °C |
| Degree of Protection | IP20 |
| Pollution Degree | 3 |
| Width in Number of Modular Spacings | 5 |
| Product Net Width | 90.0 mm |
| Product Net Height | 95.0 mm |
| Product Net Depth / Length | 82.5 mm |
| Product Net Weight | 765 g |
| Built-In Depth (t2) | 82.5 mm |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Gross Weight | 800 g |
| E-Number (Finland) | 3217585 |
| E-Number (Norway) | 1629266 |
| E-Number (Sweden) | 2101459 |
| Mounting on DIN Rail | TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715, TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715 |
| Mounting Position | Any |
| ETIM 9 | EC000042 - Miniature circuit breaker (MCB) |
| ETIM 10 | EC000042 - Miniature circuit breaker (MCB) |
| UNSPSC | 39121603 |
| eClass | V11.0 : 27141901 |
| IDEA Granular Category Code (IGCC) | 4899 >> Miniature circuit breaker (MCB) screw-in model |
| Object Classification Code | F |
| Standards | IEC/EN 60947-2, UL 1077 |
| extended_product_type | S803P-D125 |
| category_paths | Products > Low Voltage Products and Systems > Modular DIN Rail Products > High Performance Circuit Breakers HPCBs > High Performance Circuit Breakers HPCBs - S800 |
