Артикул: 1SVR730885R3300
· Производитель: ABB
· EAN: 4016779851893
1SVR730885R3300
В наличии на нашем складе
Наличие в РФ
20 259.49 ₽
в наличии на складе · 64 шт.
Склад в Китае
19 309.32 ₽
срок ≈1 мес. (38 дн.)
Склад в Европе
17 491.97 ₽
срок ≈1 мес. (38 дн.)
The CM-MPS.21S is a multifunctional relay from the CM three-phase monitors range. It operates with a rated control supply voltage / three-phase measuring voltage of 180-280 V AC 50/60 Hz and has a 2 c/o (SPDT) output with contacts rated at 250 V / 4 A. This relay is also suitable to monitor single-phase mains. It monitors all phase parameters such as over/undervoltage, phase unbalance, phase failure as well as an interrupted neutral. The corresponding threshold values are adjustable. Phase sequence monitoring as well as an ON or OFF tripping delay are selectable. The tripping delay is adjustable over a range of instantaneous to 30 s (0, 0.1-30 s). A sealable transparent cover for protection against unauthorized changes is available as accessory. The device offers screw connection technology with double-chamber cage connection terminals.
Варианты поставки
| Склад | Цена | Срок | Наличие | Мин. партия | |
|---|---|---|---|---|---|
| Склад в Европе | 17 491.97 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Европе | 18 555.31 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Китае | 19 309.32 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в России | 20 259.49 ₽ | 5 дн. | 64 шт. | — | Заказать |
| Склад в Китае | 20 483.13 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Европе | 20 598.71 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Наш склад | 21 394.00 ₽ | В наличии | 2 шт. | — | Заказать |
| Склад в Китае | 22 292.04 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Китае | 22 738.84 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Китае | 26 891.86 ₽ | ≈2 нед. (17 дн.) | под заказ | — | Заказать |
| Склад в Европе | 30 277.73 ₽ | уточняется | под заказ | — | Заказать |
| Склад в Европе | 34 329.74 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Китае | 37 896.47 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
Характеристики
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85364900 |
| Product Net Width | 22.5 mm |
| Product Net Height | 85.6 mm |
| Product Net Depth / Length | 103.7 mm |
| Product Net Weight | 0.146 kg |
| Function | Over- and undervoltage monitoring, Phase failure detection, Phase unbalance detection, Phase sequence monitoring, Interrupted neutral monitoring |
| Measuring Range | (L-N) 180 ... 280 V AC |
| Time Range | Tripping Delay (ON or OFF) 0 s |
| Rated Control Supply Voltage (Us) | (L-N) 180 ... 280 V AC |
| Rated Frequency (f) | Supply Circuit 50/60 Hz |
| Output | 2 C/O Contacts |
| Terminal Type | Screw Terminals |
| Rated Operational Current AC-12 (Ie) | (230 V) 4 A |
| Rated Operational Current AC-15 (Ie) | (230 V) 3 A |
| Rated Operational Current DC-12 (Ie) | (24 V) 4 A |
| Rated Operational Current DC-13 (Ie) | (24 V) 2 A |
| Minimum Switching Capacity | 24 V, 10 mA |
| Rated Impulse Withstand Voltage (Uimp) | Input Circuit 6 kV, Output Circuit 4 kV |
| Rated Insulation Voltage (Ui) | Input Circuit / Output Circuit 600 V, Output Circuit 1 / Output Circuit 2 300 V |
| Degree of Protection | Housing IP50, Terminals IP20 |
| Overvoltage Category | III |
| Pollution Degree | 3 |
| Short-Circuit Protective Devices | Output Circuit NC - F Type Fuses 6 A, Output Circuit NO - F Type Fuses 10 A |
| Electrical Durability | AC-12 100000 cycle |
| Mechanical Durability | Nr. Operations 30000000 cycle |
| Connecting Capacity | Flexible with Ferrule 1x 0.5 ... 2.5 mm², Flexible with Ferrule 2x 0.5 ... 1.5 mm², Flexible with Insulated Ferrule 1x 0.5 ... 2.5 mm², Flexible with Insulated Ferrule 2x 0.5 ... 1.5 mm², Flexible 1x 0.5 ... 2.5 mm², Flexible 2x 0.5 ... 1.5 mm², Rigid 1x 0.5 ... 4 mm², Rigid 2x 0.5 ... 2.5 mm² |
| Tightening Torque | 0.6 ... 0.8 N·m |
| Wire Stripping Length | 8 mm |
| Recommended Screw Driver | 4.5, 0.8 x 4, Pozidriv 1 |
| Mounting Position | 1 ... 6 |
| Mounting on DIN Rail | TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715, TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715 |
| Standards | CAN/CSA C22.2 No.14, IEC/EN 63000, IEC/EN 60255-27, IEC/EN 61000-6-2, IEC/EN 61000-6-3, UL 508 |
| Maximum Operating Voltage UL/CSA | Output Circuit 300 V AC |
| Contact Rating UL/CSA | B300 |
| Connecting Capacity UL/CSA | Flexible 1x 18-14 AWG, Flexible 2x 18-16 AWG, Rigid 2x 20-14 AWG, Rigid 1x 20-12 AWG |
| Tightening Torque UL/CSA | 7.08 in·lb |
| Pilot Duty UL/CSA | B300 |
| Flammability According to UL94 | V-0 |
| Ambient Air Temperature | Operation -25 ... +60 °C, Storage -40 ... +85 °C |
| Maximum Operating Altitude Permissible | Without Derating 2000 m |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| SCIP | eca471ea-b2ec-42a3-a10d-98ecd0c53f85 Germany |
| Simplified SCIP | 10940a4a-e940-4cb4-ab1a-14fa0ca5d858 Finland, 6c9668f9-700c-4253-94bb-447f49479950 Bulgaria, 2a085096-4e94-4ec3-beed-fa4546cd11ce Germany, d775775a-b045-470e-b14d-d02a1569f386 France, 3baf56c9-183b-4af5-96dd-f295b02b612b Belgium, 6f35dfe6-5cb0-4ceb-804f-cd0f88553cf1 Hungary, 908b5687-8ae8-4dec-a612-c87d194295e1 Portugal, 9812ee27-0ec8-4d3b-9af7-ec11d2c0e745 Spain, 6b52f8db-a754-4834-bd77-f23da8c521dc Sweden, ced1c277-2ab0-476e-9009-69c57b1c56ec France, 387fe0a5-5087-4437-900a-1e56e10080e5 Belgium, cc119799-5e6b-4c26-91df-e2720ad644a7 Hungary, fba9cca7-aa0c-42d8-9355-255eb8c0c279 Germany, 1a5edcf2-b120-4c20-93a6-74da1d7751dd Poland, 54db8fa0-c077-481a-9271-59fdbeae141b Denmark, 989a969e-61ba-4676-8324-a392a41454a1 Czechia, 9fb297f2-f95a-4142-b180-799094d1462d Germany, c8742e04-7769-46c7-aa2a-386a3b27ad0b Netherlands, 70a40233-c45e-4bb3-a847-1e303a6ace18 Germany, 1e5d7778-a702-4565-bdaf-9cd6988e05a2 Italy, 9ecb932a-f3b1-4f09-9b92-55ddc37bbc08 Croatia, 075ab626-1a3a-44bb-a7cf-115b7e8d66ad Norway, 69e65afe-7e9e-4d2a-9e87-354fb67d26ba Poland, 3c53ecec-aa37-4f52-94a3-16643936547b Estonia, 20c0b904-4dc3-4f79-bf25-8466e75c6d63 Poland, c35e213a-4a38-4ad2-b45c-f5e3b8472e04 Sweden, edf05874-9a61-4c68-8689-9f052b0ef195 Greece |
| ABB EcoSolutions | Yes |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 97 mm |
| Package Level 1 Depth / Length | 30 mm |
| Package Level 1 Height | 109 mm |
| Package Level 1 Gross Weight | 0.171 kg |
| Object Classification Code | B |
| ETIM 7 | EC001441 - Phase monitoring relay |
| ETIM 8 | EC001441 - Phase monitoring relay |
| ETIM 9 | EC001441 - Phase monitoring relay |
| eClass | V11.0 : 27371803 |
| UNSPSC | 39122332 |
| E-Number (Finland) | 2712272 |
| E-Number (Norway) | 4188132 |
| E-Number (Sweden) | 3860590 |
| extended_product_type | CM-MPS.21S |
