Артикул: 1SDA067803R1
· Производитель: ABB
· EAN: 8015644695668
1SDA067803R1
В наличии на нашем складе
Наличие в РФ
38 104.00 ₽
в наличии на складе · 2 шт.
Склад в Китае
30 475.05 ₽
срок ≈1 мес. (45 дн.)
Склад в Европе
33 673.27 ₽
срок ≈1 мес. (38 дн.)
C.BREAKER TMAX XT2S 160 FIXED THREE-POLE WITH FRONT TERMINALS AND SOLID-STATE RELEASE IN AC EKIP DIP LS/I R 100 A
Варианты поставки
| Склад | Цена | Срок | Наличие | Мин. партия | |
|---|---|---|---|---|---|
| Склад в Китае | 30 475.05 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Европе | 33 673.27 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Европе | 36 639.22 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Китае | 37 171.79 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Наш склад | 38 104.00 ₽ | В наличии | 2 шт. | — | Заказать |
| Склад в Европе | 38 540.51 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Китае | 40 445.89 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Китае | 42 544.71 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Европе | 46 931.57 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Китае | 51 807.58 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Европе | 51 855.39 ₽ | уточняется | под заказ | — | Заказать |
Характеристики
| ABB EcoSolutions | Yes |
| ABB Site Meeting Group Waste To Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| Extended Product Lifetime | Product Modularity |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 55.70 % |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| SCIP | 7209862d-7595-4e15-b73c-999f9db2a58e China |
| Simplified SCIP | 327ef865-49c5-434f-af11-b789a330622b Denmark, 661bd626-e314-4f06-9cc0-751d3216a9c5 Sweden, 54109214-0bbc-41ae-8b2a-f0e17be7025f Germany, 3e6fd98c-8981-4bfa-a6b8-adfd7e7ecec6 Estonia, 42b2c469-1407-4356-92c2-7fb96dd52465 Netherlands, aed798a2-9196-4c14-b454-f775c67008e3 Bulgaria, e3358e2a-e9f7-4bfb-bcea-5beb1ae571cd Norway, bbdd4a1e-2880-4602-ae9f-0e102ff71b62 Sweden, a393c122-55e1-45b0-948b-ce16bfb27032 Poland, 45911ba3-591f-4683-9c0d-d87040fdf6c8 France, d5973fe0-aaa7-4c14-87e4-3bcb0b981d5d Belgium, 1a8cbff2-5da9-4bec-98a0-f2bb51e3e6c7 Poland, 48ed4cf4-145c-4058-aa04-d7763c75ed08 Hungary, 68902358-c4c1-4ee1-8665-f340c326fa5b Belgium, 156bb17b-21b0-454b-9df1-de9bffadafb7 Germany, 412e8272-dc87-468e-bf5f-eafef2d42d11 Croatia, fa9089f3-82b4-41c6-8b80-6807ea27a844 Finland, 4de0ad80-00fd-4ee2-a5b0-dd6aa20de808 Czechia, ba028109-23bc-40af-aa34-897e01dd8aea Greece, f2f37518-8eef-4c4f-baa4-4e6338159f3d Poland, c288c417-64a2-4b54-8873-732d82183943 Germany, 2c99aa1c-f963-4dcf-88f4-550003efe5de Germany, 99d743e1-71a1-4eed-800c-942cf67eff3b Portugal, f7e59319-cd25-478e-a794-f100fc558e7e Spain, c1ac0a4a-effd-49fb-b013-d8b535b96564 Germany, 864b5625-13cd-48db-b41c-b67a3688757e Hungary, 1aebcf64-72d6-484c-be6e-5e3da0c7608c France |
| Order Code US and Canada | XT2SE3100EFF000XXX |
| E-Number (Finland) | 3640580 |
| E-Number (Norway) | 4309655 |
| E-Number (Sweden) | 3182029 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85362090 |
| Product Net Width | 90 mm |
| Product Net Height | 130 mm |
| Product Net Depth / Length | 82.5 mm |
| Product Net Weight | 1.4 kg |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 130 mm |
| Package Level 1 Height | 208 mm |
| Package Level 1 Depth / Length | 145 mm |
| Package Level 1 Gross Weight | 1.714 kg |
| Circuit Breaker Type to be Associated | Power Distribution |
| Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker |
| Product Type | Automatic Circuit Breaker |
| Version | F |
| Connecting Capacity Main Circuit | Busbar 32.5..100 mm² |
| Current Type | AC |
| Electrical Durability | 120 cycles per hour, 8000 cycle |
| Mechanical Durability | 240 cycles per hour, 25000 cycle |
| Number of Poles | 3P |
| Opening Time | CB with SOR 30 ms, CB with UVR 30 ms |
| Order Multiple | 1 piece |
| Power Loss | at Rated Operating Conditions per Pole 4.2 W |
| Rated Current (In) | 100 A |
| Rated Frequency (f) | 50 / 60 Hz |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Voltage | 690 V AC |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (220 V AC) 85 kA, (230 V AC) 85 kA, (240 V AC) 85 kA, (380 V AC) 50 kA, (415 V AC) 50 kA, (440 V AC) 50 kA, (500 V AC) 36 kA, (525 V AC) 25 kA, (690 V AC) 12 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (220 V AC) 85 kA, (230 V AC) 85 kA, (240 V AC) 85 kA, (380 V AC) 50 kA, (415 V AC) 50 kA, (440 V AC) 50 kA, (500 V AC) 36 kA, (525 V AC) 25 kA, (690 V AC) 12 kA |
| Rated Uninterrupted Current (Iu) | 160 A |
| Rated Voltage (Ur) | 690 V |
| Recommended Screw Driver | Main Circuit M6 |
| Release | Ekip Dip LS/I |
| Release Type | EL |
| Short-Circuit Performance Level | S |
| Standards | IEC60947-2 |
| Sub-type | XT2 |
| Terminal Connection Type | Front |
| Terminal Type | Bolt |
| Tightening Torque | 6 N·m |
| ETIM 9 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 10 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| Object Classification Code | Q |
| UNSPSC | 39120000 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 |
| extended_product_type | XT2S 160 Ekip Dip LS/I In=100A 3p F F |
