Артикул: 1SDA067416R1
· Производитель: ABB
· EAN: 8015644013103
1SDA067416R1
В наличии на нашем складе
Наличие в РФ
11 119.00 ₽
в наличии на складе · 1 шт.
Склад в Китае
9 834.74 ₽
срок ≈2 мес. (73 дн.)
Склад в Европе
13 289.15 ₽
срок ≈4 мес. (122 дн.)
C.BREAKER TMAX XT1N 160 FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMD R 100-1000 A
Варианты поставки
| Склад | Цена | Срок | Наличие | Мин. партия | |
|---|---|---|---|---|---|
| Склад в Китае | 9 834.74 ₽ | ≈2 мес. (73 дн.) | под заказ | — | Заказать |
| Наш склад | 11 119.00 ₽ | В наличии | 1 шт. | — | Заказать |
| Склад в Китае | 11 424.02 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в России | 11 638.96 ₽ | 5 дн. | 100 шт. | — | Заказать |
| Склад в Европе | 13 289.15 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Китае | 14 669.84 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Европе | 14 849.62 ₽ | ≈2 мес. (73 дн.) | под заказ | — | Заказать |
| Склад в Европе | 15 268.79 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в России | 15 510.97 ₽ | 5 дн. | 36 шт. | — | Заказать |
| Склад в Китае | 16 719.05 ₽ | ≈2 мес. (73 дн.) | под заказ | — | Заказать |
| Склад в Китае | 16 855.15 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Европе | 17 417.60 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Европе | 17 592.99 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Китае | 19 227.22 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Китае | 19 420.83 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Европе | 23 823.65 ₽ | уточняется | под заказ | — | Заказать |
Характеристики
| ABB EcoSolutions | Yes |
| ABB Site Meeting Group Waste To Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| Extended Product Lifetime | Product Modularity |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 55.9 % |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| SCIP | 9dc23701-0389-4d5d-9536-ba4ecc672f9f Italy |
| Simplified SCIP | dd3b120b-cdd6-4746-84e1-3b6ba8deac82 Germany, 8ebd8f62-f8d3-47fd-bae4-333e0a218076 Greece, db9cca29-2669-426f-bf76-0e2f3f91228f Portugal, 01cd358c-7878-4350-a8cb-ad98bcdf704c Bulgaria, b0a036f2-b8f0-4f7f-aefc-8d094fa47899 Sweden, 996ed7e4-edc7-4d81-acaa-2cb3aad20176 Poland, 8fd3fa87-f754-4249-8c2f-b59e41939151 France, c53d77de-041e-4093-a986-0c6cc61f57c5 Sweden, 84ac0468-5c88-4c5d-8651-f235b69841f9 Norway, fbb53485-dd85-4069-8b43-658e7c5756b5 Finland, d200e345-117c-45cc-aa41-8ed4a9afed60 Netherlands, 1a85d563-57df-4b20-b426-89ccb3c219e0 Germany, e9fc3286-418a-43e6-a8da-5755bebb9679 Denmark, b375cf2b-78f3-4e1e-ae01-a1a61a24b8a8 Germany, d6dca289-557a-48dd-b4aa-fd4b82c36b75 Croatia, 83b9a438-3162-4bc0-be90-1012a3e4b3fc Poland, 4f0681cb-c9f4-4a2f-abaf-3d07ac967890 Germany, 3b489665-c6a7-4f01-ac7f-d84483cd1553 France, e6c6fa22-a8fe-4514-a81d-fcf5be2a7031 Netherlands, c4a7c5cf-16cb-45a7-8b0f-07ab801af36a Spain, 83b9a438-3162-4bc0-be90-1012a3e4b3fc Poland, 84ac0468-5c88-4c5d-8651-f235b69841f9 Norway, fbb53485-dd85-4069-8b43-658e7c5756b5 Finland, b0a036f2-b8f0-4f7f-aefc-8d094fa47899 Sweden, 2bcd0110-606e-4b4a-96e7-796264c5d0b9 Netherlands, 996ed7e4-edc7-4d81-acaa-2cb3aad20176 Poland, 8fd3fa87-f754-4249-8c2f-b59e41939151 France, c53d77de-041e-4093-a986-0c6cc61f57c5 Sweden, 8b19cf35-ed11-4fe7-8969-08b832056cec Germany, 3acf60b8-4063-465a-b3fd-a4c165e3f530 Czechia, 5dc72b3c-ae87-4b2b-b761-495b6eb5d7eb Poland, cb2acb5b-5523-4886-9a78-19a9c1e14bee Netherlands, 1216d8d6-e907-4c14-bafd-557686032dbe Netherlands, 87f2c02c-07fc-4c8f-9140-875e6fa9b620 Estonia, 8ebd8f62-f8d3-47fd-bae4-333e0a218076 Greece, db9cca29-2669-426f-bf76-0e2f3f91228f Portugal, 8b19cf35-ed11-4fe7-8969-08b832056cec Germany, 4f0681cb-c9f4-4a2f-abaf-3d07ac967890 Germany, 3b489665-c6a7-4f01-ac7f-d84483cd1553 France, e6c6fa22-a8fe-4514-a81d-fcf5be2a7031 Netherlands, c4a7c5cf-16cb-45a7-8b0f-07ab801af36a Spain, 2bcd0110-606e-4b4a-96e7-796264c5d0b9 Netherlands, 01cd358c-7878-4350-a8cb-ad98bcdf704c Bulgaria, d200e345-117c-45cc-aa41-8ed4a9afed60 Netherlands, 1a85d563-57df-4b20-b426-89ccb3c219e0 Germany, e9fc3286-418a-43e6-a8da-5755bebb9679 Denmark, b375cf2b-78f3-4e1e-ae01-a1a61a24b8a8 Germany, d6dca289-557a-48dd-b4aa-fd4b82c36b75 Croatia, 3acf60b8-4063-465a-b3fd-a4c165e3f530 Czechia, 5dc72b3c-ae87-4b2b-b761-495b6eb5d7eb Poland, cb2acb5b-5523-4886-9a78-19a9c1e14bee Netherlands, 1216d8d6-e907-4c14-bafd-557686032dbe Netherlands, 87f2c02c-07fc-4c8f-9140-875e6fa9b620 Estonia |
| E-Number (Finland) | 3640527 |
| E-Number (Norway) | 4379208 |
| E-Number (Sweden) | 3182429 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85362090 |
| Product Net Width | 76.2 mm |
| Product Net Height | 130 mm |
| Product Net Depth / Length | 70 mm |
| Product Net Weight | 1.1 kg |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 128 mm |
| Package Level 1 Height | 135 mm |
| Package Level 1 Depth / Length | 143 mm |
| Package Level 1 Gross Weight | 1.133 kg |
| Circuit Breaker Type to be Associated | Power Distribution |
| Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker |
| Product Type | Automatic Circuit Breaker |
| Version | F |
| Connecting Capacity Main Circuit | Busbar 45.5 ... 80 mm² |
| Current Type | AC/DC |
| Electrical Durability | 120 cycles per hour, 8000 cycle |
| Mechanical Durability | 240 cycles per hour, 25000 cycle |
| Number of Poles | 3P |
| Opening Time | CB with SOR 30 ms, CB with UVR 30 ms |
| Order Multiple | 1 piece |
| Power Loss | at Rated Operating Conditions per Pole 7 W |
| Rated Current (In) | 100 A |
| Rated Frequency (f) | 50 / 60 Hz |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Instantaneous Short-Circuit Current Setting (Ii) | 1000 A |
| Rated Insulation Voltage (Ui) | 800 V |
| Rated Operational Voltage | 690 V AC, 500 V DC |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (220 V AC) 50 kA, (230 V AC) 50 kA, (240 V AC) 50 kA, (380 V AC) 36 kA, (415 V AC) 36 kA, (440 V AC) 18 kA, (500 V AC) 15 kA, (525 V AC) 11 kA, (690 V AC) 5 kA, (250 V DC) 2 Poles in Series 36 kA, (500 V DC) 3 Poles in Series 36 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (220 V AC) 65 kA, (230 V AC) 65 kA, (240 V AC) 65 kA, (380 V AC) 36 kA, (415 V AC) 36 kA, (440 V AC) 36 kA, (500 V AC) 30 kA, (525 V AC) 22 kA, (690 V AC) 6 kA, (250 V DC) 2 Poles in Series 36 kA, (500 V DC) 3 Poles in Series 36 kA |
| Rated Uninterrupted Current (Iu) | 160 A |
| Rated Voltage (Ur) | 690 V |
| Recommended Screw Driver | Main Circuit M6 |
| Release | TMD |
| Release Type | TM |
| Setting Range | 70...100 A |
| Short-Circuit Performance Level | N |
| Standards | IEC60947-2 |
| Sub-type | XT1 |
| Terminal Connection Type | Front |
| Terminal Type | Bolt |
| Tightening Torque | 6 N·m |
| ETIM 9 | EC001023 - Shunt release (for power circuit breaker) |
| ETIM 10 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| Object Classification Code | Q |
| UNSPSC | 39120000 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 |
