Артикул: 1SDA066780R1
· Производитель: ABB
· EAN: 8015644006907
1SDA066780R1
В наличии на нашем складе
Наличие в РФ
19 909.00 ₽
в наличии на складе · 1 шт.
Склад в Китае
13 740.75 ₽
срок ≈2 мес. (73 дн.)
Склад в Европе
17 753.69 ₽
срок ≈4 мес. (122 дн.)
C.BREAKER FORMULA A2C 250 FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMF R 250-2500 A
Варианты поставки
| Склад | Цена | Срок | Наличие | Мин. партия | |
|---|---|---|---|---|---|
| Склад в Китае | 13 740.75 ₽ | ≈2 мес. (73 дн.) | под заказ | — | Заказать |
| Склад в Европе | 17 753.69 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Китае | 19 598.23 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Наш склад | 19 909.00 ₽ | В наличии | 1 шт. | — | Заказать |
| Склад в Европе | 20 197.72 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Европе | 20 499.17 ₽ | ≈2 мес. (73 дн.) | под заказ | — | Заказать |
| Склад в Европе | 21 975.43 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Китае | 22 296.18 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Китае | 23 359.28 ₽ | ≈2 мес. (73 дн.) | под заказ | — | Заказать |
| Склад в Китае | 24 258.59 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Европе | 31 242.87 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Европе | 31 614.05 ₽ | уточняется | под заказ | — | Заказать |
Характеристики
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| SCIP | ff258522-d72c-4c17-95a4-e0a14caabe7a Italy |
| Simplified SCIP | 787ec71f-e2d6-489c-9dcf-bcaa7197d43a Poland, 74c27028-1bd7-4a77-b583-405ae587753f Belgium, 50a4204c-843f-429f-81d8-2c78b8d2d1b2 Spain, fc241675-51a2-452e-a051-484164100fe4 Poland, 61737986-7fbf-48be-8a23-84774c4636ca Norway, 1c245da9-1049-4d2a-9b57-3a037b923033 France, 95746890-3ecf-4b70-887b-aab828783e8b Germany, 2e8d4576-2e20-4b18-9433-b14fd8b8a913 Sweden, ab524073-6c7e-43ad-902a-4e2da3b35783 Germany, c024758c-26d6-44b1-9f37-1237313a6a58 France, 3bd87268-5428-49a5-9306-87f1742d5f1b Hungary, aedcab81-405d-4428-93cb-96596e964882 Netherlands, fb19c251-dcae-40b8-a711-cf7c62b2ab72 Croatia, 771ceec6-19bd-4a77-b3b7-3dd512691282 Greece, fbb4b0f3-70ce-4596-8793-6ce87693ce84 Bulgaria, c211197e-4cb4-403f-86af-72e547c7cc85 Portugal, a2480442-3f4d-4d68-a0ff-931e11a769a2 Czechia, aee14f2b-ba36-4334-a895-b9dceaf93d83 Germany, 424aff46-14d4-4dd3-86d6-b5f88ae77214 Finland, 392b63e0-8ec5-435f-a615-6b454fab89cf Belgium, d6d4f896-8b3e-40c5-9516-31abadeac65f Poland, 8dd21901-f879-47cf-906b-678a5aa1e48a Germany, 5d939946-b3ee-423c-a564-7b66c0cc9755 Denmark, a2ff4d04-fdcc-47fd-a2a4-358f8478b335 Germany, 89bc4205-968c-45ab-a3c0-7c735cb87723 Sweden |
| Order Code US and Canada | ABC250TW |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85362090 |
| Product Net Width | 105 mm |
| Product Net Height | 150 mm |
| Product Net Depth / Length | 60 mm |
| Product Net Weight | 1.391 kg |
| Package Level 1 Units | 1 piece |
| Package Level 1 Width | 162 mm |
| Package Level 1 Height | 120 mm |
| Package Level 1 Depth / Length | 155 mm |
| Package Level 1 Gross Weight | 1.464 kg |
| Product Main Type | SACE FORMULA |
| Product Name | Moulded Case Circuit Breaker |
| Product Type | Automatic Circuit Breaker |
| Version | F |
| Electrical Durability | 4000 cycle |
| Mechanical Durability | 10000 cycle |
| Number of Poles | 3P |
| Opening Time | CB with SOR 15 ms, CB with UVR 15 ms |
| Power Loss | at Rated Operating Conditions per Pole 16 W |
| Rated Current (In) | Main Circuit 250 A |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Rated Insulation Voltage (Ui) | 690 V |
| Rated Operational Voltage | 550 V AC, 250 V DC |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (240 V AC) 25 kA, (380 V AC) 12.5 kA, (415 V AC) 12.5 kA, (440 V AC) 10 kA, (480 V AC) 9 kA, (500 V AC) 4 kA, (250 V DC) 2 Poles in Series 12.5 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (240 V AC) 50 kA, (380 V AC) 25 kA, (415 V AC) 25 kA, (440 V AC) 20 kA, (480 V AC) 18 kA, (500 V AC) 8 kA, (250 V DC) 2 Poles in Series 25 kA |
| Rated Uninterrupted Current (Iu) | 250 A |
| Release | TMF |
| Release Type | TM |
| Short-Circuit Performance Level | C |
| Standards | IEC |
| Sub-type | A2 |
| Terminal Connection Type | Front |
| ETIM 9 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 10 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| Object Classification Code | Q |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 |
| extended_product_type | A2C 250 TMF 250-2500 3p F F |
| category_paths | Products > Low Voltage Products and Systems > Circuit Breakers > Moulded Case Circuit Breakers > Formula DSA |
