Артикул: 1SDA066719R1
· Производитель: ABB
· EAN: 8015644694067
1SDA066719R1
В наличии на нашем складе
Наличие в РФ
8 999.00 ₽
в наличии на складе · 5 шт.
Склад в Китае
10 588.76 ₽
срок ≈4 мес. (122 дн.)
Склад в Европе
9 592.17 ₽
срок ≈4 мес. (122 дн.)
C.BREAKER FORMULA A1C 125 FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMF R 100-1000 A
Варианты поставки
| Склад | Цена | Срок | Наличие | Мин. партия | |
|---|---|---|---|---|---|
| Наш склад | 8 999.00 ₽ | В наличии | 5 шт. | — | Заказать |
| Склад в Европе | 9 592.17 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Европе | 10 139.26 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Китае | 10 588.76 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Европе | 11 032.66 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Китае | 11 192.69 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Китае | 12 178.91 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Европе | 14 445.65 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Европе | 16 147.22 ₽ | уточняется | под заказ | — | Заказать |
Характеристики
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Order Code US and Canada | AAC100TW |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85362090 |
| Product Net Width | 76.2 mm |
| Product Net Height | 130 mm |
| Product Net Depth / Length | 60 mm |
| Product Net Weight | 0.79 kg |
| Package Level 1 Units | 1 piece |
| Package Level 1 Width | 136.5 mm |
| Package Level 1 Height | 124 mm |
| Package Level 1 Depth / Length | 110.5 mm |
| Package Level 1 Gross Weight | 0.8 kg |
| Product Main Type | SACE FORMULA |
| Product Name | Moulded Case Circuit Breaker |
| Product Type | Automatic Circuit Breaker |
| Version | F |
| Electrical Durability | 1500 cycle |
| Mechanical Durability | Nr. Operations 8500 cycle |
| Number of Poles | 3P |
| Opening Time | CB with SOR 15 ms, CB with UVR 15 ms |
| Power Loss | at Rated Operating Conditions per Pole 8 W |
| Rated Current (In) | Main Circuit 100 A |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Rated Insulation Voltage (Ui) | 690 V |
| Rated Operational Voltage | 550 V AC, 250 V DC |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (240 V AC) 15 kA, (380 V AC) 12.5 kA, (415 V AC) 6.25 kA, (440 V AC) 5 kA, (480 V AC) 4 kA, (500 V AC) 2.5 kA, (250 V DC) 2 Poles in Series 5 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (240 V AC) 30 kA, (380 V AC) 25 kA, (415 V AC) 25 kA, (440 V AC) 20 kA, (480 V AC) 15 kA, (500 V AC) 8 kA, (250 V DC) 10 kA |
| Rated Uninterrupted Current (Iu) | 125 A |
| Release | TMF |
| Release Type | TM |
| Short-Circuit Performance Level | C |
| Standards | IEC |
| Sub-type | A1 |
| Terminal Connection Type | Front |
| ETIM 9 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 10 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| Object Classification Code | Q |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 |
| extended_product_type | A1C 125 TMF 100-1000 3p F F |
| category_paths | Products > Low Voltage Products and Systems > Circuit Breakers > Moulded Case Circuit Breakers > Formula DSA |
