Артикул: 1SCA022812R7340
· Производитель: ABB
· EAN: 6417019274898
1SCA022812R7340
Под заказ
Наличие в РФ
нет в наличии
Склад в Китае
37 697.48 ₽
срок ≈1 мес. (45 дн.)
Склад в Европе
38 307.74 ₽
срок ≈1 мес. (38 дн.)
Encl. Switch Disconnector, 6-p. 415V AC23 90A, 45kW. Plastic enclosure. IP65. Black Pistol handle. Interlocked cover. Defeatable interlocking. The enclosure in the OTP series is using a rigid glass reinforced polycarbonate enclosure. The enclosure is UV protected, protected against low-pressure water jets (IP65), and hence built for outdoor and indoor use. The cable entries are threaded and have knock out holes for 2 parallell cables and one control cable, both from top and bottom. The handle is padlockable and made for three padlocks. The cover is interlocked. The interlocking can be by-passed, for thermographing etc. The switch is made for 5 wire system, and have a fixed neutral terminal and PE terminal.
Варианты поставки
| Склад | Цена | Срок | Наличие | Мин. партия | |
|---|---|---|---|---|---|
| Склад в Китае | 37 697.48 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Европе | 38 307.74 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Китае | 42 287.77 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Европе | 42 696.20 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Европе | 42 711.72 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Китае | 47 132.17 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Китае | 47 149.30 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Европе | 58 054.12 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Европе | 63 286.04 ₽ | уточняется | под заказ | — | Заказать |
| Склад в Китае | 64 085.72 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
Характеристики
| countryOfOrigin | Finland |
| countryOfAssembly | Finland |
| countryOfLastProcessing | Finland |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| SCIP | 8d7d4fd1-c33f-41f0-9de5-4ba315d9dc6d Finland |
| Simplified SCIP | 498fa886-bd2a-43e0-a674-4363b1ac8da4 Germany, 8d16991b-8bfe-47a2-8410-3ece7a5c394b Germany, 88461e1f-dabc-41c6-90f7-c0f69820c7bf Denmark, 0ca0e10b-e39d-49b1-9dd5-fe1000c80a1c Bulgaria, 9a382b8a-d720-4576-8861-7a7dc439fa01 France, ae189122-7f1f-4ae8-930e-4706d95cce47 Hungary, 8b933214-1969-4c1a-bfe6-b7bb6fe510ea Italy, aa3703a4-0e6c-4322-b93d-7e95258ea5f2 Belgium, e8f15dfe-906a-49e4-ba9a-b258ae12279d Estonia, fc88d440-2db5-47d2-b0d4-afe7376780a9 Poland, 2336de59-8fb1-47ce-a73d-1c287d12c78e France, 56123d5f-76d4-465b-805a-b1d102488993 Sweden, d0d70b66-facf-4835-a771-d8d34ae31092 Poland, 84a0716f-c9df-48ff-987d-3ace6beb6692 Hungary, d22985a3-7e3c-4b36-918c-ecd9f2913b71 Netherlands, 0b293e12-88d8-41b1-b1fa-99fa56db4098 Sweden, d6ef340c-b954-4c68-86dc-1559a5174de1 Croatia, b42dd401-6dd0-446e-bf23-1dbb2b9e2567 Germany, ff6b8e73-6d41-4831-9d7a-91dfd0374cec Germany, 9774eb9d-9411-4273-aebf-870fab7d1f6e Germany, 9b56f6fe-a7cd-47eb-95c0-aaba2b242513 Czechia, f1b7cdf5-6abf-4ee3-bc94-3e6e783a618e Norway, 1e541238-352e-4249-8468-949400ec8eeb Belgium, b084cab4-d255-4d7e-bbaf-1e56f38cf0dd Poland, 53e918d7-cb88-4b4e-b47f-13475f28faf4 Spain, 6d85d855-aa4d-480b-b01a-f5d7d185688d Portugal, c3d11c46-7458-4422-9b0a-6165569d8bb1 Greece |
| Degree of Protection | acc. to IEC 60529 IP65 |
| Pollution Degree | 3 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85365080 |
| Last Ordering Date | 2027-03-31 All Countries |
| Replacement Product ID (NEW) | No new type |
| Country of Origin | Finland |
| Product Net Width | 200 mm |
| Product Net Height | 400 mm |
| Product Net Depth / Length | 140 mm |
| Product Net Weight | 3 kg |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 213 mm |
| Package Level 1 Depth / Length | 417 mm |
| Package Level 1 Height | 197 mm |
| Package Level 1 Gross Weight | 3.2 kg |
| Cable Cross-Section | 10 ... 70 mm² |
| Cable Entry Position | Top/Bottom |
| Cable Outlets Per Side | 2xM50+M16 / 2xM50+M16 |
| Color | RAL7035 |
| Connecting Capacity Main Circuit | Screw Clamp 10 ... 70 mm², Screw Clamp / PE Terminal 4pc 10 ... 70 mm² |
| Conventional Thermal Current (Ithe) | Fully Enclosed 125 A |
| Enclosure Material | Plastic |
| Handle Color | Black |
| Handle Type | Pistol |
| Impact Resistance Rating | Housing IK08 |
| Maximum Mounted Auxiliary Contacts | 2 NO, 2 NC |
| Mounted Auxiliary Contacts | 0 NO, 0 NC |
| Neutral Type | Fixed Neutral |
| Number of Auxiliary Contacts NC | 0 |
| Number of Auxiliary Contacts NO | 0 |
| Number of Poles | 6P |
| Power Loss | at Rated Operating Conditions per Pole 6.3 W, Total 37.8 W |
| Rated Insulation Voltage (Ui) | acc. to IEC/EN 60664-1 750 V |
| Rated Operational Current AC-21A (Ie) | (400 V) 125 A, (500 V) 125 A, (690 V) 125 A |
| Rated Operational Current AC-22A (Ie) | (380 ... 415 V) 125 A, (690 V) 125 A |
| Rated Operational Current AC-23A (Ie) | (380 ... 415 V) 90 A, (500 V) 70 A, (690 V) 50 A |
| Rated Operational Power AC-23A (Pe) | (380 ... 415 V) 45 kW, (500 V) 45 kW, (690 V) 45 kW |
| Rated Operational Voltage | Main Circuit 750 V |
| Rated Short-Circuit Making Capacity (Icm) | (690 V AC) 3.6 kA |
| Rated Short-time Withstand Current Low Voltage (Icw) | for 1 s 2.5 kA, for 0.2 s 2.5 kA |
| Recommended Screw Driver | Main Circuit Hexagon 4 |
| Standards | IEC 60947-1, -3 |
| Terminal Type | Screw Terminals |
| Tightening Torque | Main Circuit 6 N·m |
| Wire Stripping Length | 20 mm |
| Object Classification Code | Q |
| ETIM 9 | EC000216 - Switch disconnector (low voltage) |
| ETIM 10 | EC000216 - Switch disconnector (AC) |
| UNSPSC | 39122205 |
| IDEA Granular Category Code (IGCC) | 5166 >> Safety switch |
| eClass | V11.1 : 27371403 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| extended_product_type | OTP125B6M |
