Артикул: 1SBN060100R1000
· Производитель: ABB
· EAN: 3471523131149
1SBN060100R1000
Под заказ
Наличие в РФ
нет в наличии
Склад в Китае
4 277.07 ₽
срок ≈2 мес. (73 дн.)
Склад в Европе
5 964.26 ₽
срок ≈4 мес. (122 дн.)
RA4 is an interface relay designed to receive 24 V DC signals delivered by PLC’s or other sources with a low output power and to restore them with sufficient power to operate the coils of the relevant AF09 ... AF96 contactors or the NF contactor relays. RA4 interface relay is made up of a miniature electromechanical relay equipped with a N.O. contact and with a low consumption 24 V DC coil. The interface relay coil is controlled by the PLC while the N.O. contact ensures switching of the power contactor.
• Easy to install: less compact than other market solutions, RA4 is simply clipped on the top of the contactor
• Optimum interface: it accept all 24 VDC low outpout power signals down to 20 mA 24 V DC
• Optimize your logistics and cost, thanks to 1 single RA4 interface relay for AF09...AF96 / NF monitoring control voltages up to 250V AC, without any additional accessory or wiring for assembling.
Варианты поставки
| Склад | Цена | Срок | Наличие | Мин. партия | |
|---|---|---|---|---|---|
| Склад в Китае | 4 277.07 ₽ | ≈2 мес. (73 дн.) | под заказ | — | Заказать |
| Склад в Китае | 4 312.85 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Европе | 5 964.26 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Европе | 6 021.03 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Китае | 6 583.92 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Европе | 6 586.69 ₽ | ≈2 мес. (73 дн.) | под заказ | — | Заказать |
| Склад в Европе | 6 641.79 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Китае | 6 646.59 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Китае | 7 271.02 ₽ | ≈2 мес. (73 дн.) | под заказ | — | Заказать |
| Склад в Китае | 7 331.85 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Европе | 9 120.53 ₽ | уточняется | под заказ | — | Заказать |
Характеристики
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85364900 |
| Product Net Width | 44.8 mm |
| Product Net Depth / Length | 31.16 mm |
| Product Net Height | 40.5 mm |
| Product Net Weight | 0.04 kg |
| Standards | IEC/EN 60947-5-1, UL 60947-1, UL 60947-4-1, CSA C22.2 No. 60947-1-13, CSA C22.2 No. 60947-5-1-14 |
| Rated Frequency (f) | Control Circuit 50 / 60 Hz |
| Rated Insulation Voltage (Ui) | acc. to IEC 60947-5-1 250 V, acc. to IEC 60947-5-1 and VDE 0110 (Gr. C) 250 V AC 50/60 Hz |
| Electrical Durability | 2000000 cycle |
| Maximum Electrical Switching Frequency | 600 cycles per hour |
| Rated Control Circuit Voltage (Uc) | DC Operation 24 V |
| Connecting Capacity Control Circuit | Flexible with Ferrule 1/2x 0.75 ... 2.5 mm², Flexible with Insulated Ferrule 1x 0.75 ... 2.5 mm², Flexible with Insulated Ferrule 2x 0.75 ... 1.5 mm², Rigid Solid 1/2x 1 ... 2.5 mm², Rigid Stranded 1/2x 1 ... 2.5 mm² |
| Wire Stripping Length | Control Circuit 10 mm |
| Recommended Screw Driver | Control Circuit Pozidriv 2, Control Circuit Flat Ø 5.5 mm |
| Tightening Torque | Control Circuit 1.2 N·m |
| Terminal Type | Screw Terminals |
| Suitable For | AF09, AF09Z, AF12, AF12Z, AF16, AF16Z, AF26, AF26Z, AF30, AF30Z, AF38, AF38Z, AF40, AF52, AF65, AF80, AF96, NF22E, NFZ22E, NF31E, NFZ31E, NF40E, NFZ40E, NF44E, NFZ44E, NF53E, NFZ53E, NF62E, NFZ62E, NF71E, NFZ71E, NF80E, NFZ80E, NF33/11, NF51/11 |
| Product Name | Interface Relay |
| Connecting Capacity UL/CSA | Conductor 18 ... 14 AWG |
| Tightening Torque UL/CSA | Control Circuit 11 in·lb |
| Ambient Air Temperature | Close to Contactor for Storage -40 ... 70 °C, Near Contactor for Operation in Free Air (0.85 ... 1.1 Uc) -25 ... +60 °C, Near Contactor for Operation in Free Air (Uc) at 24 VDC -25 ... 70 °C |
| Climatic Withstand | Category B according to IEC 60947-1 Annex Q |
| Maximum Operating Altitude Permissible | Without Derating 3000 m |
| Pollution Degree | 3 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 54 mm |
| Package Level 1 Depth / Length | 54 mm |
| Package Level 1 Height | 47 mm |
| Package Level 1 Gross Weight | 0.04 kg |
| ETIM 7 | EC002498 - Accessories for low-voltage switch technology |
| ETIM 8 | EC002498 - Accessories/spare parts for low-voltage switch technology |
| ETIM 9 | EC002498 - Accessories/spare parts for low-voltage switch technology |
| UNSPSC | 39122331 |
| IDEA Granular Category Code (IGCC) | 5367 >> Control relay |
| E-Number (Sweden) | 3210710 |
| extended_product_type | RA4 |
| category_paths | Products > Low Voltage Products and Systems > Control Products > Contactors > Block Contactors, Parts & Services > Drives > Services > Spares and Consumables > Parts |
