Артикул: 2CSF202005R3630
· Производитель: ABB
· EAN: 8012542815501
Выключатель дифференциального тока (УЗО) 2п 63А 300мА тип AC F202 ABB
В наличии на нашем складе
Наличие в РФ
4 904.00 ₽
в наличии на складе · 65 шт.
Склад в Китае
нет предложений
Склад в Европе
нет предложений
The RCCBs F200 series assures protection to people and installations against fault current to earth. This product is manufactured according to international IEC standards, for the markets where it is required.
Варианты поставки
| Склад | Цена | Срок | Наличие | Мин. партия | |
|---|---|---|---|---|---|
| Наш склад | 4 904.00 ₽ | В наличии | 65 шт. | — | Заказать |
Характеристики
| Carbon Footprint (Full Lifecycle) | 5.803452 kg CO₂ eq |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 82.05 % |
| ABB Site Meeting Group Waste To Landfill Target | No non-hazardous waste is sent to a landfill, UL 2799 Zero Waste To Landfill Validation available |
| Sustainable Material Content in Packaging (wt. %) | Recycled Paper - 0 %, Recycled Paper - 3.91 %, Recycled Cardboard - 29.08 %, Recycled Cardboard - 61.23 %, Recycled Cardboard - 2.66 % |
| Extended Product Lifetime | Product Durability |
| Offered with Takeback Services | Take Back for Recycling |
| Type of Residual Current | Type AC |
| Test Voltage (Ut) | 110-254 V |
| Maximum Surge Current | 0.25 kA |
| Leakage Current Type | AC |
| Power Supply Connection | Arbitrary |
| Electrical Endurance | 10000 cycle |
| Mechanical Endurance | 20000 cycle |
| Number of Poles | 2P |
| Number of Modular Spacings per DIN Rail | 2 |
| Operating Characteristic | Instantaneous |
| Tightening Torque | 2.8 N·m |
| Accessory Type | Auxiliary contact, Auxiliary/Signal contact, Shunt trip, Undervoltage release, Overvoltage release, Motor Operating Device, Bottom fitting auxiliary contact, Autoreclosing Unit |
| Screw Terminal Type | Failsafe Bi-directional Cylinder-lift Terminal, Cage Terminal, Failsafe Biconnect Fork Top/Bottom, Failsafe Biconnect Fork Bottom |
| Accessories Available | Yes |
| Connecting Capacity | Busbar 10 mm², Rigid 25 ... 25 mm², Flexible 25 ... 25 mm² |
| Rated Cross-Section | 4 - Multi-Wired 0...25 mm², 1 - Solid-Core 25...25 mm² |
| Wire Stripping Length | 12 mm |
| Terminal Type | Screw Terminals |
| Rated Voltage (Ur) | 230 V |
| Rated Operational Voltage | 230 V |
| Rated Insulation Voltage (Ui) | 500 V |
| Rated Impulse Withstand Voltage (Uimp) | 4 kV |
| Input Voltage Type | AC |
| Rated Current (In) | 63 A |
| Rated Residual Current | 300 mA |
| Rated Conditional Short-Circuit Current (Inc) | 10 kA |
| Frequency (f) | 50/60 Hz |
| Rated Frequency (f) | 50/60 Hz |
| Power Loss | at Rated Operating Conditions per Pole 3.2 W, Total 6.4 W |
| RAL Number | Similar to RAL 7035 |
| Number of Modules | 2 |
| Maximum Operating Voltage UL/CSA | 277 V AC |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| RoHS Date | 20211115 |
| REACH Information | True - contains substances > 0.1 mass percentage |
| REACH Date | 20240429 |
| SCIP | e8229506-bdcb-47ec-b10f-6ae72c1a19bf Italy |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Consumer |
| Ambient Air Temperature | Operation -25 ... 55 °C, Storage -40 ... 70 °C |
| Degree of Protection | Terminals IP20, Housing IP40 |
| Pollution Degree | 2 |
| Resistance to Vibrations | 20 Cycles with Load 0.8 In: 1g or 0.1mm 5...150...5 Hz |
| Resistance to Shock acc. to IEC 60068-2-27 | 25g 2 shocks 13 ms |
| Width in Number of Modular Spacings | 2 |
| Product Net Width | 35 mm |
| Product Net Height | 85 mm |
| Product Net Depth / Length | 69 mm |
| Product Net Weight | 200 g |
| Built-In Depth (t2) | 69 mm |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Gross Weight | 0.235 kg |
| Mounting Type | DIN-Rail |
| Mounting Position | Any |
