Артикул: 1SBL237001R1300
· Производитель: ABB
· EAN: 3471523110939
1SBL237001R1300
В наличии на нашем складе
Наличие в РФ
4 494.26 ₽
в наличии на складе · 412 шт.
Склад в Китае
2 958.85 ₽
срок ≈2 мес. (73 дн.)
Склад в Европе
3 822.65 ₽
срок ≈4 мес. (122 дн.)
The AF26-30-00-13 is a 3 pole - 690 V IEC or 600 UL contactor with screw terminals, controlling motors up to 11 kW / 400 V AC (AC-3) or 15 hp / 480 V UL and switching power circuits up to 45 A (AC-1) or 45 A UL general use. Thanks to the AF technology, the contactor has a wide control voltage range (100-250 V 50/60 Hz and DC), managing large control voltage variations, reducing panel energy consumptions and ensuring distinct operations in unstable networks. Furthermore, surge protection is built-in, offering a compact solution. AF contactors have a block type design, can be easily extended with add-on auxiliary contact blocks and an additional wide range of accessories.
Варианты поставки
| Склад | Цена | Срок | Наличие | Мин. партия | |
|---|---|---|---|---|---|
| Склад в Китае | 2 958.85 ₽ | ≈2 мес. (73 дн.) | под заказ | — | Заказать |
| Склад в Европе | 3 822.65 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Китае | 4 219.81 ₽ | ≈4 мес. (122 дн.) | под заказ | — | Заказать |
| Склад в Европе | 4 411.80 ₽ | ≈2 мес. (73 дн.) | под заказ | — | Заказать |
| Склад в России | 4 494.26 ₽ | 5 дн. | 412 шт. | — | Заказать |
| Склад в Китае | 4 740.85 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Китае | 5 030.04 ₽ | ≈2 мес. (73 дн.) | под заказ | — | Заказать |
| Склад в Европе | 5 405.04 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Наш склад | 5 414.00 ₽ | В наличии | 9 шт. | — | Заказать |
| Склад в Китае | 5 966.60 ₽ | ≈1 мес. (38 дн.) | под заказ | — | Заказать |
| Склад в Европе | 6 693.98 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Европе | 6 817.39 ₽ | уточняется | под заказ | — | Заказать |
| Склад в Европе | 7 300.92 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
| Склад в Китае | 7 389.46 ₽ | ≈1 мес. (59 дн.) | под заказ | — | Заказать |
| Склад в Китае | 8 059.45 ₽ | ≈1 мес. (45 дн.) | под заказ | — | Заказать |
Характеристики
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85364900 |
| Product Net Width | 45 mm |
| Product Net Depth / Length | 86 mm |
| Product Net Height | 86 mm |
| Product Net Weight | 0.31 kg |
| Number of Main Contacts NO | 3 |
| Number of Main Contacts NC | 0 |
| Number of Auxiliary Contacts NO | 0 |
| Number of Auxiliary Contacts NC | 0 |
| Number of Poles | 3P |
| Standards | IEC/EN 60947-1, IEC/EN 60947-4-1, UL 60335-2-40 LZGH2 A2L, UL 60947-4-1, CSA C22.2 No. 60335-2-40 LZGH2 A2L, CSA C22.2 No. 60947-4-1 |
| Rated Operational Voltage | Main Circuit 690 V |
| Rated Frequency (f) | Control Circuit 50 / 60 Hz, Main Circuit 50 / 60 Hz |
| Conventional Free-air Thermal Current (Ith) | acc. to IEC 60947-4-1, Open Contactors Θ = 40 °C 50 A |
| Rated Operational Current AC-1 (Ie) | (690 V) 40 °C 45 A, (690 V) 60 °C 40 A, (690 V) 70 °C 32 A |
| Rated Operational Current AC-3 (Ie) | (415 V) 60 °C 26 A, (440 V) 60 °C 26 A, (500 V) 60 °C 23 A, (690 V) 60 °C 17 A, (380 / 400 V) 60 °C 26 A, (220 / 230 / 240 V) 60 °C 26 A |
| Rated Operational Current AC-3e (Ie) | (415 V) 60 °C 26 A, (440 V) 60 °C 26 A, (500 V) 60 °C 23 A, (690 V) 60 °C 17 A, (380 / 400 V) 60 °C 26 A, (220 / 230 / 240 V) 60 °C 26 A |
| Rated Operational Current DC-1 (Ie) | (110 V) 2 Poles in Series, 40 °C 45 A, (110 V) 2 Poles in Series, 60 °C 40 A, (110 V) 2 Poles in Series, 70 °C 32 A, (110 V) 3 Poles in Series, 40 °C 45 A, (110 V) 3 Poles in Series, 60 °C 40 A, (110 V) 3 Poles in Series, 70 °C 32 A, (220 V) 3 Poles in Series, 40 °C 45 A, (220 V) 3 Poles in Series, 60 °C 40 A, (220 V) 3 Poles in Series, 70 °C 32 A, (72 V) 1-Pole, 40 °C 45 A, (72 V) 1-Pole, 60 °C 40 A, (72 V) 1-Pole, 70 °C 32 A, (72 V) 2 Poles in Series, 40 °C 45 A, (72 V) 2 Poles in Series, 60 °C 40 A, (72 V) 2 Poles in Series, 70 °C 32 A, (72 V) 3 Poles in Series, 40 °C 45 A, (72 V) 3 Poles in Series, 60 °C 40 A, (72 V) 3 Poles in Series, 70 °C 32 A |
| Rated Operational Current DC-3 (Ie) | (110 V) 2 Poles in Series, 40 °C 45 A, (110 V) 2 Poles in Series, 60 °C 40 A, (110 V) 2 Poles in Series, 70 °C 32 A, (110 V) 3 Poles in Series, 40 °C 45 A, (110 V) 3 Poles in Series, 60 °C 40 A, (110 V) 3 Poles in Series, 70 °C 32 A, (220 V) 3 Poles in Series, 40 °C 45 A, (220 V) 3 Poles in Series, 60 °C 40 A, (220 V) 3 Poles in Series, 70 °C 32 A, (72 V) 1-Pole, 40 °C 45 A, (72 V) 1-Pole, 60 °C 40 A, (72 V) 1-Pole, 70 °C 32 A, (72 V) 2 Poles in Series, 40 °C 45 A, (72 V) 2 Poles in Series, 60 °C 40 A, (72 V) 2 Poles in Series, 70 °C 32 A, (72 V) 3 Poles in Series, 40 °C 45 A, (72 V) 3 Poles in Series, 60 °C 40 A, (72 V) 3 Poles in Series, 70 °C 32 A |
| Rated Operational Current DC-5 (Ie) | (110 V) 2 Poles in Series, 40 °C 45 A, (110 V) 2 Poles in Series, 60 °C 40 A, (110 V) 2 Poles in Series, 70 °C 32 A, (110 V) 3 Poles in Series, 40 °C 45 A, (110 V) 3 Poles in Series, 60 °C 40 A, (110 V) 3 Poles in Series, 70 °C 32 A, (220 V) 3 Poles in Series, 40 °C 20 A, (220 V) 3 Poles in Series, 60 °C 20 A, (220 V) 3 Poles in Series, 70 °C 20 A, (72 V) 1-Pole, 40 °C 20 A, (72 V) 1-Pole, 60 °C 20 A, (72 V) 1-Pole, 70 °C 20 A, (72 V) 2 Poles in Series, 40 °C 45 A, (72 V) 2 Poles in Series, 60 °C 40 A, (72 V) 2 Poles in Series, 70 °C 32 A, (72 V) 3 Poles in Series, 40 °C 45 A, (72 V) 3 Poles in Series, 60 °C 40 A, (72 V) 3 Poles in Series, 70 °C 32 A |
| Rated Operational Power AC-3 (Pe) | (400 V) 11 kW, (415 V) 11 kW, (440 V) 15 kW, (500 V) 15 kW, (690 V) 15 kW, (380 / 400 V) 11 kW, (220 / 230 / 240 V) 6.5 kW |
| Rated Operational Power AC-3e (Pe) | (415 V) 11 kW, (440 V) 15 kW, (500 V) 15 kW, (690 V) 15 kW, (380 / 400 V) 11 kW, (220 / 230 / 240 V) 6.5 kW |
| Rated Short-time Withstand Current Low Voltage (Icw) | at 40 °C Ambient Temp, in Free Air, from a Cold State 10 s 350 A, at 40 °C Ambient Temp, in Free Air, from a Cold State 15 min 50 A, at 40 °C Ambient Temp, in Free Air, from a Cold State 1 min 150 A, at 40 °C Ambient Temp, in Free Air, from a Cold State 1 s 700 A, at 40 °C Ambient Temp, in Free Air, from a Cold State 30 s 225 A |
| Maximum Breaking Capacity | cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 440 V 500 A, cos phi=0.45 (cos phi=0.35 for Ie > 100 A) at 690 V 200 A |
| Rated Insulation Voltage (Ui) | acc. to IEC 60947-4-1 690 V, acc. to UL/CSA 600 V |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Maximum Electrical Switching Frequency | (AC-1) 600 cycles per hour, (AC-2 / AC-4) 150 cycles per hour, (AC-3) 1200 cycles per hour |
| Maximum Mechanical Switching Frequency | 3600 cycles per hour |
| Rated Control Circuit Voltage (Uc) | 50 Hz 100 ... 250 V, 60 Hz 100 ... 250 V, DC Operation 100 ... 250 V |
| Power Loss | at Rated Operating Conditions AC-1 per Pole 1.8 W, at Rated Operating Conditions AC-3 per Pole 0.6 W |
| Operate Time | Between Coil De-energization and NC Contact Closing 13 ... 98 ms, Between Coil De-energization and NO Contact Opening 11 ... 95 ms, Between Coil Energization and NC Contact Opening 38 ... 90 ms, Between Coil Energization and NO Contact Closing 40 ... 95 ms |
| Mounting on DIN Rail | TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715, TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715 |
| Mounting by Screws (not supplied) | 2 x M4 Screws Placed Diagonally |
| Connecting Capacity Main Circuit | Flexible with Ferrule 1/2x 1.5 ... 10 mm², Flexible with Insulated Ferrule 1x 1.5 ... 10 mm², Flexible with Insulated Ferrule 2x 1.5 ... 4 mm², Rigid Solid 1/2x 2.5 ... 4 mm², Rigid Stranded 1/2x 2.5 ... 10 mm² |
| Connecting Capacity Control Circuit | Flexible with Ferrule 1/2x 0.75 ... 2.5 mm², Flexible with Insulated Ferrule 1x 0.75 ... 2.5 mm², Flexible with Insulated Ferrule 2x 0.75 ... 1.5 mm², Rigid Solid 1/2x 1 ... 2.5 mm², Rigid Stranded 1/2x 1 ... 2.5 mm² |
| Wire Stripping Length | Control Circuit 10 mm, Main Circuit 14 mm |
| Degree of Protection | acc. to IEC 60529, IEC 60947-1, EN 60529 Coil Terminals IP20, acc. to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP20 |
| Tightening Torque | Control Circuit 1.2 N·m, Main Circuit 2.5 N·m |
| Terminal Type | Screw Terminals |
| Product Name | Block Contactor |
| NEMA Size | 1 |
| Continuous Current Rating NEMA | 27 A |
| Horsepower Rating NEMA | (115 V AC) Single Phase 2 Hp, (200 V AC) Three Phase 7-1/2 Hp, (230 V AC) Single Phase 3 Hp, (230 V AC) Three Phase 7-1/2 Hp, (460 V AC) Three Phase 10 Hp, (575 V AC) Three Phase 10 Hp |
| Maximum Operating Voltage UL/CSA | Main Circuit 600 V |
| General Use Rating UL/CSA | (600 V AC) 45 A |
| Horsepower Rating UL/CSA | (120 V AC) Single Phase 2 hp, (200 ... 208 V AC) Three Phase 7-1/2 hp, (220 ... 240 V AC) Three Phase 7-1/2 hp, (240 V AC) Single Phase 3 hp, (440 ... 480 V AC) Three Phase 15 hp, (550 ... 600 V AC) Three Phase 20 hp |
| Connecting Capacity Main Circuit UL/CSA | Rigid Solid 1/2x 14-10 AWG, Rigid Stranded 1/2x 14-8 AWG |
| Connecting Capacity Control Circuit UL/CSA | Rigid Solid 1/2x 18-14 AWG, Rigid Stranded 1/2x 18-14 AWG |
| Tightening Torque UL/CSA | Control Circuit 11 in·lb, Main Circuit 22 in·lb |
| Full Load Amps Motor Use | (120 V AC) Single Phase 24 A, (200 ... 208 V AC) Three Phase 25.3 A, (220 ... 240 V AC) Three Phase 22 A, (240 V AC) Single Phase 17 A, (440 ... 480 V AC) Three Phase 21 A, (550 ... 600 V AC) Three Phase 22 A |
| Ambient Air Temperature | Close to Contactor Fitted with Thermal O/L Relay -25 ... 60 °C, Close to Contactor without Thermal O/L Relay -40 ... 70 °C, Close to Contactor for Storage -60 ... +80 °C |
| Climatic Withstand | Category B according to IEC 60947-1 Annex Q |
| Maximum Operating Altitude Permissible | Without Derating 3000 m |
| Resistance to Shock acc. to IEC 60068-2-27 | Closed, Shock Direction: B1 25 g, Open, Shock Direction: B1 5 g, Shock Direction: A 30 g, Shock Direction: B2 15 g, Shock Direction: C1 25 g, Shock Direction: C2 25 g |
| Resistance to Vibrations | 4g Closed Position & 2g Open position 5 ... 300 Hz |
| Pollution Degree | 3 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| SCIP | 7ecf2e54-f412-43b8-a8b6-f76449ceacf0 China |
| Simplified SCIP | 9d16e54f-6686-406e-b14f-0cee1717e24b Estonia, 37f3e77c-795e-41ee-b433-5c1794ce6c9f Norway, c4403672-cc97-4b2d-a454-093c5bdbe0cb Poland, cfb0408b-ba9b-48ab-901c-b020f8b19980 Poland, 50053f28-5503-45f1-9216-9c6153ff7c92 Croatia, 6b0d03d8-ef7c-4172-83cb-7d93cddc8742 Germany, ed8aca28-3375-4793-aa35-19886c194ca8 Czechia, c2440a4a-0fc3-4333-b049-16519c9881df Hungary, 9d2c81de-3f4d-4249-a51b-c1b177e19539 Belgium, afa8983c-e5a2-4fde-b1d7-6bf2e8d96c79 Sweden, 485bc883-a6ce-4552-a15a-da10257b9607 France, 14d33d6f-4b5e-4e0e-b342-8cfc4ba5a2c9 Poland, b8c1ba93-f584-410e-92b8-54d0ba47a423 Germany, de3d8d83-9e65-4128-8963-0d0484118cb3 France, 531e9494-6c9c-4abc-a5af-da0b16b0f7ef Germany, 8233522d-460d-47d7-a4cd-1e65521b7d63 Germany, 2cfe5e3d-3504-4045-864e-2829c08e0738 Denmark, 5e33d089-78e4-4d6b-8056-dd2f81a6aacc Sweden, 30aa3dc6-6fdb-459e-845e-8598288ccde5 Germany, 4aefcb2d-c513-4f5e-a9a4-32a65a38d38f Portugal, 494382ca-a4c6-41e3-a2ba-63b24bdfff79 Belgium, d41d1cf2-832c-4c8c-b21b-2c05c687541b Greece, 41a24e46-e6a4-4f72-b9d0-f89775cf0a5f Bulgaria, ce0aed02-bd40-49e4-b9b4-cfd41985524a Hungary, b07f208c-c45d-421b-8981-bfcef052fa0d Netherlands, c2dff4eb-46ff-42c4-a65b-a1a9ee75a19d Spain, 24fc9fcb-5e79-463c-963b-c3d91fa717e5 Finland |
